ADDiTEC Hybrid 3 3D Printer & CNC Machine

Introducing the ADDiTEC Hybrid 3 Multi-Tech Platform

ADDiTEC Hybrid 3

Advanced Features for Superior Hybrid Manufacturing Efficiency

Equipped with cutting-edge Liquid Metal Jetting (LMJ), Laser Directed Energy Deposition (LDED), and CNC machining, the ADDiTEC Hybrid 3 delivers a unique combination of additive and subtractive manufacturing processes for unmatched precision and versatility.

Multi-Material Flexibility: With two additive processing heads, the Hybrid 3 supports multi-material printing, enabling parts with varying material properties to meet diverse industrial demands.

High-Resolution and High-Rate Capabilities: LMJ technology unlocks high-resolution printing for intricate details, while LDED achieves fast deposition rates using low-cost, standard welding wire, ensuring efficient and economical production.

Hybrid Manufacturing with CNC Machining: The integrated subtractive process provides post-machining capabilities, achieving desired surface finishes and tight tolerances for parts printed using both LMJ and LDED processes, maximizing functionality and precision.

Applications
Ideal for industries such as aerospace, automotive, and heavy machinery, the ADDiTEC Hybrid 3 transforms the production of complex parts with its multi-process approach, enabling scalable, cost-effective manufacturing across a wide range of applications.

Parameters
Maximum Laser Power: 6 kW
Laser Type: Fiber laser
Laser Wavelength: 1080 nm
Layer Thickness: Laser DED 0.8-1.2 mm / LMJ 0.24 mm (min.)
Maximum Deposition Rate: Laser DED 4 kg/hr / LMJ 0.5 lb/hr
Wire Feed Stock: Laser DED 0.8 – 1.2 mm / LMJ 1.6 mm
Resolution: Laser DED 2.5 mm / LMJ 0.5 mm
Process Control Closed Up: Laser DED YES / LMJ YES

CNC Machining
Build volume: (mm) 900 x 500 x 500
Max. Spindle Speed: 12000 rpm
Max. Cutting Speed: 1-20000 mm/min
Table Size (mm): 510×1100
Max. Load on Table: 500 kg

Accuracy as per ISO-230-2
Positioning Accuracy: 0.01mm
Repeatability Accuracy: 0.008 mm

Currently there are no materials assigned. You can view our full range of materials here.

Currently there are no case studies assigned. You can view our full range of case studies here.

Leasing 3D Printers

If you’re looking to 3D printer leasing, Tri-Tech 3D provide direct rental contracts on our full range of 3D printers, which can include post processing equipment and extended warranty, making your investment into 3D printing both affordable and help plan your annual expenditure.

How do I lease a 3D Printer?

The process is quite simple! First, you’ll need to undergo a credit check. This can be done quickly, usually within 24-48 hours. If you’re a new start-up company or sole trader, it may be more difficult to obtain finance, but deposit payments and directors guarantees can help. Talk to a leasing company to get a pre-proposed finance plan without any obligation. Once approved, you’ll know what value technology you can consider.

Funding in the most part, is provided by our sister company Stanford Marsh Finance (a division of the Stanford Marsh Group) or via our numerous strategic finance partners/brokers.

Rates are frequently checked to ensure competitiveness in the market place and you will find our terms highly attractive.  With options such as fixed term contracts, step rentals which make payments lower in the earlier years allowing time to grow the use from your new device.  Or deferred payment, enabling you to benefit from the technology ahead of when you start paying.

Why lease 3D Printers?..

Not only can leasing be financially beneficial to companies, but it can also give you the ability to remain ahead and current with technology. It also means your entry point to utilisation of a professional 3D printer is far more affordable than you may think – a professional 3D printer from as little as £299 per month, (including a wash system and 12-months support).

Furthermore, if like many companies today you are outsourcing 3D printing via a 3D Print Bureau, you are already spending an amount each month that when converted to a lease, could represents an in-house option at no extra cost (savings possibly).  Either talk to one of our team, or send us details of your average spend and we can help provide an ROI report.

In addition to our excellent rates, as an end user dealing directly with one vendor for finance, equipment and after sales care, your rental agreement will provide you with a future flexible upgrade path. We’ve enabled companies to acquire new technology prior to the completion of the minimum rental period, without the usual high termination figure charged by outside finance agencies.

All finance is subject to approval and none of the solutions detailed above are guaranteed to suit all scenarios. What we can promise however, is we will do our utmost to make the finance of your 3D Print solution as affordable and easy as possible.

What are the main benefits of leasing a 3D printer?

Leasing a 3D printer has many benefits compared to outright purchase. Leases are usually affordable, good for cashflow, and allow you to invest in more equipment without large amounts of money upfront. If you already outsource 3D print work, leasing can help you bring production in-house and may improve workflow and protect your intellectual property. Additionally, there are well-documented taxation benefits to companies in regard to leases.

When to lease VS buy a 3D printer?

When deciding whether to lease or buy a 3D printer, consider your needs. If you have a proven requirement and plan to run a system to its end-of-life, outright purchase may be best. However, if you want to keep your options open and stay up-to-date with new technology, leasing provides flexibility to upgrade at the end of a minimum leasing period.

I’m not ready to lease or buy a 3D printer – is a service an option?

If you’re not ready to lease or buy a 3D printer, outsourcing to a print bureau could be a great option. Companies like 3D Print Bureau offer access to a team of experts running a variety of professional 3D printers in different technologies. This allows you to pay as you go for the end part until your volume hits a level where bringing production in-house makes sense.

If you are interested in further information, please contact us.
